Front kit for 2 elements with 1 Schuko socket base, 1 key, and 1 left USB charger matte white Simon 100

The front kit for 2 elements with Schuko socket base, switch, and USB charger from the Simon 100 series is a practical and modern solution for integrating multiple electrical points in a single unit. This kit combines functionality and design, offering a power outlet, a lighting control switch, and a USB charger for electronic devices all in one piece.

Designed within the innovative Simon 100 series, this set stands out for its contemporary aesthetics, ease of use, and ability to simplify daily life. Its design integrates three essential functions in a single installation point: a Schuko socket, a switch for lighting or switching, and a USB charger ideal for charging smartphones, tablets, or other electronic devices.

This type of solution is especially recommended for spaces such as bedrooms, where having a socket, a switch, and a USB charging point near the bed provides great convenience.

The kit offers comfortable operation thanks to its rocker-push button system and intuitive design. It also incorporates connection systems designed to make the installer's job easier:

• Quick-connect terminals (1 click) on the main mechanisms
• USB charger connection via screw terminal

In terms of electrical performance, the set is designed for safe and efficient use:

• Schuko socket base: 16 A
• Switch / crossover: 10 AX
• USB charger: 2.1 A
• Nominal voltage: 250 V~

The kit is made of high-quality thermoplastic material that provides good mechanical resistance and long service life. Its design ensures stable performance under normal domestic or professional use conditions.

Additionally, it features an IP20 protection rating, suitable for indoor installations.

Main features:

• Series: Simon 100
• Product type: Front kit
• Configuration: 2 elements
• Included components:
  • 1 Schuko socket base
  • 1 switch
  • 1 USB charger
• Format: Schuko + USB
• Finish: Glossy black
• Material: Thermoplastic
• Dimensions: 154.5 x 83.5 mm
• Protection rating: IP20

Electrical performance:

• Schuko socket current: 16 A
• Crossover current: 10 AX
• USB charger: 2.1 A
• Nominal voltage: 250 V~

Operating conditions:

• Operating temperature: 5 ºC to 40 ºC
• Storage temperature: -25 ºC to 50 ºC

Installation:

• Installation type: Suitable for flush mounting
• Installation orientation: Horizontal
• Compatible with Simon 100 kits and mechanisms

Standards:

• Directive 2014/35/EU LVD
• Directive 2014/30/EU EMC
• Directive 2011/65/EU RoHS
• EN 50581:2012
• EN 60669-1:1999 + A1:2002 + A2:2008
• EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2011

Box contents:

• Kit cover and switches

Maintenance:

• Clean with a soft, dry cloth
• Do not use abrasive cleaners or products containing chlorine

The Simon 100 front kit allows you to concentrate several electrical functions in a single point in an elegant, modern, and practical way, maintaining the characteristic aesthetics of this series.

It is an especially convenient solution for areas such as bedrooms or workspaces, where having a socket, lighting control, and USB charging in the same place makes everyday life much more practical.
